Filter Cartridges for assembly onto Spigot
- Filter side inside
- Cleaning by rotationg brushes or vibration
Applications
Mobile and stationary dust collectors
Building materials industry
Separation of wood dust and flakes
Dust from grinding
Production of glass
- Polyester
The filter material is adapted to the properties of the dust. Our filter media are certified according to DIN EN 60335-2-69 or DIN EN 1822.
Special filter media for unusual operating conditions are available on request.
Maximum operating temperature: 80 °C
Possible equipment:
- Antistatic
- Oil and water repellent
Top closed
Ø A [mm] |
Ø C [mm] |
Length L [mm] |
Filter area [m²] |
---|---|---|---|
240 | 230 | 661 | 3,1 |
490 | 480 | 638 | 6,7 |
490 | 500 | 638 | 6,7 |
240 | 230 | 1041 | 5,2 |
490 | 480 | 1018 | 11,0 |
490 | 500 | 1018 | 11,0 |
For brush cleaning system
Ø A [mm] |
Ø C [mm] |
Length L [mm] |
Filter area [m²] |
---|---|---|---|
240 | 230 | 661 | 3,1 |
490 | 480 | 638 | 6,7 |
490 | 500 | 638 | 6,7 |
240 | 230 | 1041 | 5,2 |
490 | 480 | 1018 | 11,0 |
490 | 500 | 1018 | 11,0 |
Accessory rotating brushes with crank
Part no. |
---|
310-006-000011 |
310-006-000011 |
310-006-000015 |
310-006-000015 |
Technical changes reserved.
We implement your requirements
Are you looking for a solution for a new area of application in dedusting or do you have unusual operating conditions? Our technicians and engineers are happy to develop your individual solution!
